Leica FlexLine TS03 Total Station

Leica FlexLine TS03 Manual Total Station, best-in-class and easy to use, a classic manual total station for standard measuring tasks, enabling you to carry out most survey and layout tasks easily and efficiently.

Package includes;

• Leica TS03 5” (1.5mgon) R500 Total Station, Reflectorless R500 EDM
• RS232 Interface
• USB Stick/SD Card Interface
• 2GB Internal Flash Memory
• 1GB SDRAM
• Laser Plummet
•  Keyboard with 3.5” QVGA Black & White Display
• Quick Guide
• Protective Cover
• Lens Hood
• Cleaning Cloth
• Container

Leica FlexLine TS03 Manual Total Station

The Leica FlexLine TS03 and TS07 high-quality, manual total stations are based on a proven product concept that has been revolutionising the world of measurement  and survey for nearly 200 years. The instruments are equipped with a comprehensive application-based software package - Leica FlexField software - that  enables most survey and stakeout tasks to be carried out easily and efficiently. The new FlexLine manual total stations work reliably and deliver accurate results even in harsh environments

• WORK FASTER: Measure more points per day due to faster measurement and stakeout procedures (endless drives, trigger key, drives on both sides, pinpoint EDM and more), supported by our easy-to-use and familiar FlexField software. Speed up your learning curve onsite, take advantage of the great ergonomics and reliable measurements. Reduce errors and rework.
• USE IT TROUBLE-FREE: Increase productivity and minimise downtime by relying on instruments that simply work and come with a global service and support network.
• CHOOSE PRODUCTS THAT ARE BUILT TO LAST: Even after years of use under harsh conditions (like mud, dust, blowing rain, extreme heat and cold), FlexLine still operates with the same high level of accuracy and reliability.
• CONTROL YOUR INVESTMENT: Instrument quality has been our standard for almost 200 years, which is why you can count on a lower investment over the entire instrument lifetime and do not have to worry about unexpected costs.
• SAVE TIME WITH AUTOHEIGHT: measure, read and set the instrument height automatically with this revolutionary feature in the FlexLine TS07 (optional).  Errors are minimised and the setup process onsite is faster.

Be it building construction, civil engineering or surveying and mapping – the TS03 helps you tackle your daily challenges and tasks trouble-free:

• Managing directors of construction departments benefit from minimal downtime of your survey crews to deliver projects under budget and in time
• Survey managers can rely on the highest product durability in the market, which increases your planning certainty.
• Surveyors work faster by measuring more points per day with less measurement errors and rework.

Leica FlexLine: The new generation of manual total stations
The new Leica FlexLine series is based on a proven product concept, revolutionising the world of measurement and survey for nearly 200 years. Unlike any other manual total stations in the market, Leica Geosystems manual total stations focus on providing the highest quality, the lowest total cost of ownership and the longest durability in the industry, enabling users to work with purpose-driven solutions for the best performance results.

Leica FlexField software: Comprehensive, intuitive and easy to use
The TS03 is equipped with the Leica FlexField software, an intuitive, easy-to-use and familiar software. Guided workflows and easy to understand graphics and icons ensure a low learning curve when working in the field. The software makes the interpretation of measurement values or text no longer necessary and guarantees a faster and simple operation when you need it. With its pinpoint distance measurement system, you will be able to measure to both prisms and any surfaces.

Service and support: Global, local and best-in-class
The new FlexLine manual total stations are supported by superior after sales service and support. With the Active Customer Care program and myWorld customer portal, users have access to latest software updates, service and support as well as to mySecurity. With mySecurity activated, the locking mechanism ensures the device is disabled and can no longer be used.

LEICA FLEXLINE TS03 TOTAL STATION TECHNICAL SPECIFICATIONS
		Leica FlexLine TS03	Leica FlexLine TS07	Leica FlexLine TS10
ANGULAR MEASUREMENT
Accuracy Hz and V	Absolute, continuous, diametrical	2’’ / 3’’ / 5’’	1’’ / 2’’ / 3’’ / 5’’ / 7“	1’’ / 2’’ / 3’’ / 5’’
	Display resolution: 0.1’’ (0.1 mgon) Quadruple axis compensation Compensator setting accuracy2: 0.5’’ / 1’’/ 1.5’’ / 2’’ Compensator range: +/- 4’ Electronic level resolution: 2“ Circular level sensitivity: 6` / 2 mm
DISTANCE MEASUREMENT
Range	Prism (GPR1, GPH1P): 0.9 m to 3,500 m Prism GPR1 (Long Range mode) > 10,000 m
	Non-Prism / Any surface R5003 R10004		.	.
Accuracy / Measurement time	Single prism Precise+ / Once: 1 mm + 1.5 ppm (typical 2.4 s) Precise&Fast / Once&Fast: 2 mm + 1.5 ppm (typical 2 s) Tracking / Continously: 3 mm + 1.5 ppm (typical < 0.15 s) Averaging: 1 mm + 1.5 ppm Long Range mode / > 4 km: 5 mm + 2 ppm (typical 2.5 s)
	Non-Prism / Any surface 0 m - 500 m: 2 mm + 2 ppm (typical 2.4 s5) > 500 m: 4 mm + 2 ppm
Laser dot size	At 30 m: 7 mm x 10 mm At 50 m: 8 mm x 20 mm At 100 m: 16 mm x 25 mm
Telescope	Magnification: 30x Resolving power: 3” Focusing range: 1.55 m / 5.08 ft to infinity Field of view: 1°30’ / 1.66 go/ 2.7 m at 100 m
GENERAL
Display and keyboard		3.5“ (inch), 320 x 240 px QVGA, grayscale, 28 keys	3.5“ (inch), 320 x 240 px QVGA, colour, touch, 28 keys	5“ (inch), 800 x 480 pixels WVGA, colour, touch, 25 keys6b, (optional:37 keys with function keys)
	2nd keyboard		.	.
	Key illumination
Operation	Endless drives for HZ & V Trigger-Key: user definable with 2 functions
Power management	Exchangeable Lithium-Ion battery7 Operating time with GEB364 Operating time with GEB334	up to 32 h up to 16 h	up to 32 h up to 16 h	up to 26 h up to 13 h
	Battery charging time with GKL341 charger for GEB364 / GEB334 GKL311 charger for GEB364 / GEB334	3 h 30 min / 3 h 6 h 30 min / 3 h 30 min	3 h 30 min / 3 h 6 h 30 min / 3 h 30 min	3 h 30 min / 3 h 6 h 30 min / 3 h 30 min
	External supply voltage Nominal voltage 13.0 V DC & 16 W max
Data storage	Internal memory: 4 GB Flash Memory card: SD card 1 GB or 8 GB USB memory stick: 1 GB
Processor	TI OMAP4430 1GHz Dual-core ARM® Cortex A9 MPCore Operating system – Windows EC7
Interfaces	RS2328, USB device
	Bluetooth, WLAN
	Mobile Data sidecover: LTE-Modem for internet access		.	.
Guide Light (EGL)	Working range: 5 m to 150 m Position accuracy: 5 cm at 100 m Wavelength red /orange: 617 nm / 593 nm		(R1000)	(R1000)
Laser plummet (Laserclass)	Accuracy Plumb line deviation: 1.5 mm at 1.5 m instrument height Diameter of laser point: 2.5 mm at 1.5 m instrument height
AutoHeight module for automatic instrument height measurement (Laserclass)	Accuracy Distance accuracy: 1.0 mm (1 Sigma) Distance range: 0.7 m to 2.7 m		.
Weight		4.3 kg	4.3 - 4.5 kg	4.4 - 4.9 kg
Environmental specifications	Working temperature range: –20°C to +50°C11 Arctic version: –35°C to +50°C Dust / Water (IEC 60529) / Humidity: IP66 / 95%, non-condensing Military Standard 810G, Method 506.5		.	.
Imaging	5 megapixel CMOS sensor Overview camera with field of view 19.4			.
LOC8	Tracking and theft deterrence device	.	.	.

Documentation
